Opis
WiFi 6 usmjerivač s pet gigabitnih portova, idealan za kućni internet do 1000 Mbps, podržava spajanje velikog broja uređaja i smanjuje kašnjenje u mreži.
Hardverske specifikacije
- CPU: 1.3 GHz dvojezgreni ARM Cortex-A53
- Flash/ROM: 128 MB (1 Gbit) NAND
- DDR/RAM: 256 MB (2 Gbit) DDR3
- 5 GHz Wi-Fi brzina: 2402 Mbps
- 2.4 GHz Wi-Fi brzina: 574 Mbps
- 5 GHz Wi-Fi tokovi: 2T2R (2×2 MIMO) s dodatnim strujanjem
- 2.4 GHz Wi-Fi tokovi: 2T2R (2×2 MIMO)
- Wi-Fi antene: 4 fiksne
- Pojačala (FEM / PA/LNA): 5 GHz: 3 interna; 2.4 GHz: 2 interna
- Beamforming: Da
- Domet: Maksimalno 200 m (testirano u otvorenom prostoru)
- Performanse kroz zidove: Dva drvena zida < 10 cm; jedan betonski zid < 20 cm ili dva betonska zida < 10 cm
- Gigabit RJ45 portovi: 5 (1× WAN + 4× LAN)
- LED indikatori: Power, Internet, WAN, LAN, 2.4 GHz Wi-Fi, 5 GHz Wi-Fi
- Tipke: WPS, Reset
- Napajanje: DC 12V 1A (adapter ulaz 100–240 V AC, izlaz 12V 1A DC)
- Maksimalna potrošnja energije: 11.5 W
- Potrošnja u mirovanju: 4.2 W
- Radna temperatura: 0 ℃ ~ 40 ℃
- Temperatura skladištenja: -40 ℃ ~ 70 ℃
- Vlažnost: 10% ~ 90% (bez kondenzacije)
- Vlažnost skladištenja: 5% ~ 95% (bez kondenzacije)
- Certifikati: FCC, CE
- Instalacija: Stolna ili zidna montaža
- Dimenzije uređaja: 183.3 × 109 × 38 mm
- Dimenzije antena: 175 mm svaka
- Težina proizvoda: 330 g
- Sadržaj pakiranja: WR3000E, adapter, Ethernet kabel, vodič za instalaciju
- Težina maloprodajnog pakiranja: 737.6 g
- Dimenzije maloprodajnog pakiranja: 330 × 256 × 60 mm
- Broj jedinica u kartonu: 10
- Dimenzije kartona: 52.8 × 31.7 × 34.7 cm
- Bruto težina kartona: 8.2 kg
- Neto težina kartona: 7.3 kg
Softverske specifikacije
- Wi-Fi standardi: Wi-Fi 6
- Maksimalna modulacija Wi-Fi: 1024-QAM
- Wi-Fi učinkovitost: OFDMA, MU-MIMO, BSS Color
- Maksimalni kapacitet: 512 uređaja
- Preporučeni maksimalni broj klijenata: 200
- Maksimalna širina Wi-Fi kanala: 160 MHz
- Wi-Fi sigurnost: WPA/WPA2/WPA3
- Gostujuća mreža: 2.4 GHz, 5 GHz
- WPS: Da
- Radni načini: Wi-Fi Router, Access Point, Range Extender, WISP, Client
- Mesh: Cudy Mesh, Wireless Backhaul, Wired Backhaul, Multi-Band Backhaul
- WAN mode: DHCP, Static IP, PPPOE, PPTP, L2TP
- QoS: Per-User Rate Limiting
- DHCP: Address Reservation, DHCP Client List, Server
- IP verzije: IPv4/IPv6
- IPv6 protokoli: Relay, Dynamic (SLAAC/DHCPv6), Static (Fixed IP), Passthrough, 464XLAT, MAP-E, DS-Lite
- IPTV/VLAN: Bridge, Tag VLAN, VoIP VLAN, IPTV VLAN
- TTL prilagodba: Extend, Spoof, Custom
- IGMP: IGMP Proxy, IGMP Snooping
- Forwarding: Port Forwarding, Port Triggering, UPnP, DMZ
- Firewall: SPI Firewall, DoS Protection, Block PING
- Application Layer Gateway: IPSec Passthrough, L2TP Passthrough, PPTP Passthrough, FTP Passthrough, TFTP Passthrough, H323 Passthrough, SIP Passthrough, RTSP Passthrough
- VPN Server: WireGuard, OpenVPN, IPsec, PPTP, L2TP
- VPN Client: WireGuard, OpenVPN, IPsec, PPTP, L2TP
- VPN performanse: OpenVPN Client (UL/DL): 90/120 Mbps, OpenVPN Server (UL/DL): 180/160 Mbps, WireGuard Client (UL/DL): 224/230 Mbps, WireGuard Server (UL/DL): 360/314 Mbps
- DNS opcije: DNS over TLS, Manual DNS, Rebind Protection, Override Clients’ DNS, DNS over TLS Providers: Cloudflare, Google, Quad9, Custom
- Captive Portal: Da
- Wake on LAN: Da
- Online detekcija: Da
- Roditeljska kontrola: Profiles Settings, Offline Time, Online Time, Pause the Internet, Web Filter
- Upravljanje uređajima: Wi-Fi Time Schedule, MAC Filter, IP/MAC Binding, Internet On/Off, VPN On/Off, Online Time Schedule, Device Rename
- Content Management: Domain Filter, IP Filter
- LED kontrola: Da
- Metode lokalne kontrole: Config Web Page, App Control
- Metode daljinske kontrole: Config Page via HTTPS, App Control, TR069/TR098/TR111/TR143/TR181
- Nadogradnja firmware-a: Local Update, App (Over the Air), Online Update
- Pouzdanost: Timed Reboot, Backup i Restore
- Alati za dijagnostiku: Diagnosis, Ping, Traceroute, NSLookup, System Log
- Dashboard: Internet Status, Mesh Status, Devices Management, WAN Status, LAN Status, WISP Status, Wi-Fi Status, VPN Status, DHCP Server Status, System Version
- Charts: Mesh Topology, Internet Speed, WISP Speed, Wi-Fi Speed
